Panasonic SC-TM72DV - Disassembly and Assembly of Main Components

16.6 After replacement of DVD Module
Below steps is to be performed after changing of DVD Module
1. Press
on remote control while pressing “STOP” on main unit.
2. FL will display “INITIALIZE”.
3. Press “STOP” & “ENTER” on remote control (For reset of unit)
4. FL will display “DVD RESET” before change to TOC reading again.
5. Power off the set. Unplug AC cord & wait for few seconds.
6. Plug in AC cord & power on set.
17 Disassembly and Assembly of Main
Component
17.1 Disassembly flow chart
17.2 Disassembly of Top Cabinet
17.3 Disassembly for DVD changer unit
17.3.1 Disassembly of the DVD Module P.C.B.
17.4 Disassembly for Panel P.C.B., MIC P.C.B. & Tact Switch P.C.B.
17.4.1 Disassembly of Lid
17.5 Disassembly of Main P.C.B., Power P.C.B., , Power Amp P.C.B., Power Supply P.C.B., Transformer P.C.B. &
Voltage Selector P.C.B.
17.5.1 Disassembly of Power Amp P.C.B.
17.5.2 Disassembly of Power P.C.B.
17.5.3 Disassembly of Power Supply P.C.B.
17.5.4 Disassembly of Transformer P.C.B. & Voltage Selector P.C.B.
17.6 Replacement for traverse deck
17.7 Replacement for optical pickup unit (DVD mechanism)
17.8 Procedure for removing CD loading mechanism
17.9 CR16 mechanism disassembly procedure
17.9.1 Gear for servicing information
17.9.2 Replacement for the disc tray
17.9.3 Replacement for the traverse deck
17.9.4 Disassembly for CD loading unit
17.10 CR16 MECHANISM ASSEMBLY PROCEDURE
17.11 Disassembly for Traverse Unit
17.12 Disassembly of Deck Mechanism Unit
17.12.1 Replacement for the CD motor ass ’ y, capstan belt A, capstan belt B and winding belt
17.13 Replacement for the cassette lid ass ’ y
17.14 Counter-measure for tape trouble
