Panasonic TH-50PH9UK - Electrical Replacement Parts List

17.2. Electrical Replacement Parts
List
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
F101.10
2
K5D103BMA001 TIME LAG FUSE HIGH 2
F201 216005BP FUSE 250V 5A 1
F301 216005BP FUSE 250V 5A 1
F501 216002BP FUSE 250V 2A 1
A101,02 RA362MSV7 ARRESTOR 2
C10 K1MN55BA0076 55P CONNECTOR 1
C20 K1MN55BA0076 55P CONNECTOR 1
C21 K1MN80BA0076 80P CONNECTOR 1
C22 K1MN20BA0231 20P CONNECTOR 1
C31 K1MN55BA0076 55P CONNECTOR 1
C32 K1MN20BA0231 20P CONNECTOR 1
C33 K1KA04AA0150 4P CONNECTOR 1
C41 K1MN68BA0076 68P CONNECTOR 1
C42 K1MN20BA0231 20P CONNECTOR 1
C43 K1KA12BA0107 12P CONNECTOR 1
C44 K1KA04BA0107 4P CONNECTOR 1
C50 K1MN55BA0076 55P CONNECTOR 1
C51 K1MN80BA0076 80P CONNECTOR 1
C52 K1MN20BA0231 20P CONNECTOR 1
C60 K1MN55BA0076 55P CONNECTOR 1
C101 ECQU2A105ML P 1UF, 250V 1
C102 ECQU2A224ML P 0.22UF, 250V 1
C103,04 ECKENA221KBR C 221P 250V 2
C106,07 MMXC2W105K C 1P 450V 2
C108 ECJ2XB1H223K C 0.022UF, K, 50V 1
C109 ECJ2FB1H104K C 0.1UF, K, 50V 1
C110 ECJ2XC1H471J C 470PF, J, 50V 1
C111 ECJ2XB1H102K C 1000PF, K, 50V 1
C112 KZE1E470 C 470U 25V 1
C113 ECJ2XC1H471J C 470PF, J, 50V 1
C114 ECJ2XC1H101J C 100PF, J, 50V 1
C115 ECQE6472B45 C 4700U 630V 1
C116,17 KMQ2W221L C 220U 450V 2
C118 ECJ2FB1H104K C 0.1UF, K, 50V 1
C119 ECKDNA331KB7 C 330PF, Z, 1
C120 ECJ2FB1H104K C 0.1UF, K, 50V 1
C121 ECJ2XB1H223K C 0.022UF, K, 50V 1
C122,23 ECJ2FB1H104K C 0.1UF, K, 50V 2
C127 KMQ2W221L C 220U 450V 1
C128 TBB106K1A C 10U 10V 1
C129 ECJ2FB1H104K C 0.1UF, K, 50V 1
C201,02 KZE1E470 C 470U 25V 2
C203,04 RR3DD101K7 C 100P 2KV 2
C206 ECWH8473HV P 0.047PF, J, 8KV 1
C251 KMQ220901Z C 900U 220V 1
C253,54 KMQ220901Z C 900U 220V 2
C256,57 ECQE2473SKF C 0.047U 250V 2
C301 KZE1E470 C 470U 25V 1
C302,03 RR3DD101K7 C 100P 2KV 2
C305 ECWH8183HV C 0.018UF 800V 1
C306 KZE1E470 C 470U 25V 1
C351-53 KZE1E182S C 1800UF 25V 3
C354,55 ECQV1H474JL P 0.47UF, J, 50V 2
C356 KZE1E821L C 8200UF 25V 1
C357 TEB104K5 C 0.1UF 50V 1
C358 KZE1E331S C 330UF 25V 1
C359 TEB104K5 C 0.1UF 50V 1
C360 KZE1E101 C 100UF 25V 1
C361 TEB104K5 C 0.1UF 50V 1
C363 KZE1E821L C 8200UF 25V 1
C364 TEB104K5 C 0.1UF 50V 1
C365 KZE2A270 C 27UF 100V 1
C401 KZE2A270 C 27UF 100V 1
C402 KZE2A471S C 470UF 100V 1
C404,05 KZE2A471S C 470UF 100V 2
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C501 ECQU2A473ML P 0.047UF, M,250V 1
C502,03 ECJ2FB1H104K C 0.1UF, K, 50V 2
C504 KZE1E101 C 100UF 25V 1
C505 KZE1E470 C470U25V 1
C506 KXG2W330 C 330UF 450V 1
C508 ECJ2FB1H104K C 0.1UF, K, 50V 1
C509 ECJ2XB1H103K C 0.01UF, K, 50V 1
C510 KZE1H101 C 100UF 50V 1
C514 KZE1E101 C 100UF 25V 1
C515 ECJ2FB1H104K C 0.1UF, K, 50V 1
C551 ECKENA221KBR C 220P 250V 1
C552 KZE1E331S C 330UF 25V 1
C555 TBB474K2 C 0.47UF 25V 1
C556 KZE1E101 C 100UF 25V 1
C557 TBB475K1 C 4.7UF 16V 1
C558 KZE1A471 C 470UF 10V 1
C559-61 TEB104K5 C 0.1UF 50V 3
C801 F2H1V221A004 E 220UF, 35V 1 PAVCA
C802 F2H1E471A010 E 470UF, 25V 1 PAVCA
C804 ECJ1VB1H472K C 4700PF, K, 50V 1
C805 ECJ1VB1C105K C 0.01UF, K, 16V 1
C806 ECJ1VB1E104K C 0.10UF, K, 25V 1
C807 ECJ3YF1E225Z C 2.2UF, Z, 25V 1 PAVCA
C808 ECJ1VB1E104K C 0.10UF, K, 25V 1
C809 ECJ3YB1C225K C 0.022UF, K, 16V 1
C811 EEVHB1C471 E 470UF, 16V 1
C812 F2H1E471A010 E 470UF, 25V 1 PAVCA
C814 ECJ1VB1H472K C 4700PF, K, 50V 1
C815 ECJ1VB1C105K C 0.01UF, K, 16V 1
C816 ECJ1VB1E104K C 0.10UF, K, 25V 1
C817 ECJ3YF1E225Z C 2.2UF, Z, 25V 1 PAVCA
C818 ECJ1VB1E104K C 0.10UF, K, 25V 1
C819 ECJ3YB1C225K C 0.022UF, K, 16V 1
C821 EEVHB1C471 E 470UF, 16V 1
C822 F2H1E471A010 E 470UF, 25V 1 PAVCA
C823 ECJ1XC1H470J C 47PF, J, 50V 1
C824 ECJ1VB1H103K C 0.001UF, K, 50V 1
C825 ECJ1VB1C105K C 0.01UF, K, 16V 1
C827 ECJ3YF1E225Z C 2.2UF, Z, 25V 1 PAVCA
C828 ECJ1VB1E104K C 0.10UF, K, 25V 1
C829 ECJ3YB1E106M C 10 UF, K, 25V 1
C831 EEEHB1C470P C 47PF, J, 16V 1
C832 ECJ1VB1E104K C 0.10UF, K, 25V 1
C833 ECJ1VB1H103K C 0.001UF, K, 50V 1
C834,35 EEEHB1C470P C 47PF, J, 16V 2
C837 F1J0J1060004 C 0.010UF, K, 16V 1
C838 ECJ3YB1C225K C 0.022UF, K, 16V 1
C839 F1J0J1060004 C 0.010UF, K, 16V 1
C840 ECJ3YB1C225K C 0.022UF, K, 16V 1
C841 F1J0J1060004 C 0.010UF, K, 16V 1
C843 ECJ3YB1E106M C 10 UF, K, 25V 1
C844 ECJ3YB1C225K C 0.022UF, K, 16V 1
C845 ECJ3YB1E106M C 10 UF, K, 25V 1
C846 ECJ3YB1C225K C 0.022UF, K, 16V 1
C847 F1J0J1060004 C 0.010UF, K, 16V 1
C848 ECJ3YB1C225K C 0.022UF, K, 16V 1
C850 ECQB1H104JF P 0.1UF, J, 50V 1
C852 ECA1EM471 E 470UF, 25V 1
C854 EEUFC1C471 E 470UF, 16V 1
C855-57 ECJ1VB1H103K C 0.001UF, K, 50V 3
C858 F2H1E471A010 E 470UF, 25V 1 PAVCA
C859 ECJ1VB1C105K C 0.01UF, K, 16V 1
C860 EEVHB1C471 E 470UF, 16V 1
C861 ECJ1VB1H472K C 4700PF, K, 50V 1
C863 ECJ3YF1E225Z C 2.2UF, Z, 25V 1 PAVCA
C864 ECJ1VB1E104K C 0.10UF, K, 25V 1
C865 ECJ1VB1H103K C 0.001UF, K, 50V 1
C866,67 ECJ1VB1E104K C 0.10UF, K, 25V 2
C868,69 ECJ3YB1C225K C 0.022UF, K, 16V 2
C1530 ECJ3XB0J106M C 10UF, M,6.3V 1
C2350,5
1
ECJ3YB1C225K C 0.022UF, K, 16V 2
137
