Panasonic TH-50PH9UK - Page 42

TH-50PH9UK
P-BOARD PARTS LOCATION
TH-50PH9UK
P-BOARD PARTS LOCATION
Parts LocationParts Location
P-BOARD (COMPONENT SIDE)
IC101 B-3
IC401 E-5
IC501 H-3
MC101 C-3
MC201 G-3
MC202 E-3
MC301 D-3
MC502 G-2
MC601 G-4
MC701 B-5
IC
MODULE
PC503 G-4
PC505 G-4
PC506 B-4
PHOTO COUPLER
VR251 H-5
VR351 D-4
VR401 E-5
VOLUME
Q301 C-3
Q302 C-3
Q401 E-5
Q402 D-4
Q404 C-5
Q405 D-5
Q501 H-3
TRANSISTOR
P-BOARD (FOIL SIDE)
IC101 H-3
IC401 F-5
IC501 B-3
MC101 G-3
MC201 C-3
MC202 D-3
MC301 F-3
MC502 C-2
MC601 C-4
MC701 H-5
IC
MODULE
PC503 C-4
PC505 C-4
PC506 H-4
VR251 C-5
VR351 F-4
VR401 E-5
PHOTO COUPLER
VOLUME
Q103 H-2
Q104 H-2
Q106 H-2
Q301 H-3
Q302 G-3
Q351 F-5
Q352 G-5
Q353 F-5
Q354 F-4
Q401 F-4
Q402 G-4
Q403 E-4
Q404 G-5
Q405 F-5
Q406 E-4
Q501 B-3
Q502 B-3
Q551 G-5
Q552 G-6
Q553 G-6
TRANSISTOR
P
TH-50PH9UK
42
