Parker AC10 series User Manual

Function Parameters 9-29
AC10 Inverter
0HZ voltage dead zone will be valid when corresponding setting for lower limit of input is less
than 1.00.
·
W
h
e
n
F421 is set to 0, local keypad panel is working. When F421 is set to 1, remote control keypad
panel is working, and local keypad panel will be invalid for saving energy.
The remote control panel is connected by 8-cores net cable.
AC10 can supply one analog output channel AO1.
F423 AO1 output range
Setting range:
0: 0～5V;
1: 0～10V or 0~20mA
2: 4~20mA
Mfr’s value: 1
F424 AO1 lowest corresponding
frequency (Hz)
Setting range: 0.0～F425
Mfr’s value: 0.05
F425 AO1 highest corresponding
frequency (Hz)
Setting range: F424～F111
Mfr’s value: 50.00
F426 AO1 output compensation (%)
Setting range: 0～120
Mfr’s value: 100
AO1 output range is selected by F423. When F423=0, AO1 output range selects 0-5V, and
when F423=1, AO1 output range selects 0-10V or 0-20mA. When F423=2, AO1 output range
selects 4-20mA (When AO1 output range selects current signal, please turn the switch J5 to “I”
position.
Correspondence of output voltage range (0-5V or 0-10V) to output frequency is set by F424 and
F425. For example, when F423=0, F424=10 and F425=120, analog channel AO1 outputs 0-5V
and the output frequency is 10-120Hz.
AO1 output compensation is set by F426. Analog excursion can be compensated by setting
F426.
F431 AO1 analog output signal
selecting
Setting range:
0: Running frequency;
1: Output current;
2: Output voltage;
3: Analog AI1;
4: Analog AI2;
5: Input pulse
6: Output torque;
7: Given by PC/PLC;
8: Target frequency
Mfr’s value: 0
When output current is selected, analog output signal is from 0 to twice rated current.
When output voltage is selected, analog output signal is from 0V to rated output voltage (230V
or 400V).
F433 Corresponding current for full
range of external voltmeter
Setting range:
0.01～5.00 times of rated current
Mfr’s value: 2.00
F434 Corresponding current for full
range of external ammeter
Mfr’s value: 2.00
In case of F431=1 and AO1 channel for token current, F433 is the ratio of measurement range
of external voltage type ammeter to rated current of the inverter.
F421 Panel selection
Setting range: 0: Local keypad panel
1: Remote control keypad panel
2: local keypad + remote control keypad
Mfr’s value: 1
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
