Relion 1900e/2900e Manual
123 Revision 1.3
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicabil
ity
Sensor Type
Event/Rea
ding Type
Event Offset Triggers
Contrib. To
System Status
Assert
/De-
assert
Readabl
e
Value/
Offsets
Event
Data
Rearm
Stand-
by
IO Module2 Presence
(IO Mod2 Presence)
13h
Platform-
specific
Module/Board
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As
and
De
– Trig Offset M -
Baseboard Temperature 5
(Platform Specific)
14h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard Temperature 6
(Platform Specific)
15h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
IO Module2 Temperature
(I/O Mod2 Temp)
16h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
PCI Riser 3 Temperature
(PCI Riser 3 Temp)
17h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
PCI Riser 4 Temperature
(PCI Riser 4 Temp)
18h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard +1.05V
Processor3 Vccp
(BB +1.05Vccp P3)
19h
Platform-
specific
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.05V
Processor4 Vccp
(BB +1.05Vccp P4)
1Ah
Platform-
specific
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard Temperature 1
(Platform Specific)
20h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Front Panel Temperature
(Front Panel Temp)
21h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
SSB Temperature
(SSB Temp)
22h All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
