Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicabil
ity
Sensor Type
Event/Rea
ding Type
Event Offset Triggers
Contrib. To
System Status
Assert
/De-
assert
Readabl
e
Value/
Offsets
Event
Data
Rearm
Stand-
by
Exit Air Temperature
(Exit Air Temp)
2Eh
Chassis
and
Platform
Specific
Temperature
01h
Threshold
01h
This sensor does not
generate any events.
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Network Interface Controller
Temperature
(LAN NIC Temp)
2Fh All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Fan Tachometer Sensors
(Chassis specific
sensor names)
30h–
3Fh
Chassis
and
Platform
Specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc =
Degraded
c = Non-
fatal
Note3
As
and
De
Analog R, T M -
Fan Present Sensors
(Fan x Present)
40h–
4Fh
Chassis
and
Platform
Specific
Fan
04h
Generic
08h
01 - Device inserted OK
As
and
De
-
Triggered
Offset
Auto -
Power Supply 1 Status
(PS1 Status)
50h
Chassi
s-
specific
Power Supply
08h
Sensor
Specific
6Fh
00 - Presence
OK
As
and
De
– Trig Offset A X
01 - Failure
Degraded
02 – Predictive Failure
Degraded
03 - A/C lost
Degraded
06 – Configuration
error
OK
Power Supply 2 Status
(PS2 Status)
51h
Chassi
s-
specific
Power Supply
08h
Sensor
Specific
6Fh
00 - Presence
OK
As
and
De
– Trig Offset A X
01 - Failure
Degraded
02 – Predictive Failure
Degraded
03 - A/C lost
Degraded
06 – Configuration
error
OK
Power Supply 1
AC Power Input
(PS1 Power In)
54h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2
AC Power Input
(PS2 Power In)
55h
Chassis-
specific
Other Units
0Bh
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
