Relion 1900e/2900e Manual
Revision 1.0 126
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicabil
ity
Sensor Type
Event/Rea
ding Type
Event Offset Triggers
Contrib. To
System Status
Assert
/De-
assert
Readabl
e
Value/
Offsets
Event
Data
Rearm
Stand-
by
Power Supply 1 +12V % of
Maximum Current Output
(PS1 Curr Out %)
58h
Chassis-
specific
Current
03h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2 +12V % of
Maximum Current Output
(PS2 Curr Out %)
59h
Chassis-
specific
Current
03h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 1 Temperature
(PS1 Temperature)
5Ch
Chassis-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2 Temperature
(PS2 Temperature)
5Dh
Chassis-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Hard Disk Drive 15 - 23
Status
(HDD 15 - 23 Status)
60h
–
68h
Chassis-
specific
Drive Slot
0Dh
Sensor
Specific
6Fh
00 - Drive Presence
OK
As
and
De
– Trig Offset A
X
X
01- Drive Fault
Degraded
07 - Rebuild/Remap
in progress
Degraded
Processor 1 Status
(P1 Status)
70h All
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip
Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 2 Status
(P2 Status)
71h All
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip
Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 3 Status
(P3 Status)
72h
Platform-
specific
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip
Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 4 Status
(P4 Status)
73h
Platform-
specific
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip
Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 1 Thermal Margin
(P1 Therm Margin)
74h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 2 Thermal Margin
(P2 Therm Margin)
75h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 3 Thermal Margin
(P3 Therm Margin)
76h
Platform-
specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
