Relion 1900e/2900e Manual
127 Revision 1.3
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicabil
ity
Sensor Type
Event/Rea
ding Type
Event Offset Triggers
Contrib. To
System Status
Assert
/De-
assert
Readabl
e
Value/
Offsets
Event
Data
Rearm
Stand-
by
Processor 4 Thermal Margin
(P4 Therm Margin)
77h
Platform-
specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 1 Thermal
Control %
(P1 Therm Ctrl %)
78h All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 2 Thermal
Control %
(P2 Therm Ctrl %)
79h All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 3 Thermal
Control %
(P3 Therm Ctrl %)
7Ah
Platform-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 4 Thermal
Control %
(P4 Therm Ctrl %)
7Bh
Platform-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor ERR2 Timeout
(CPU ERR2)
7Ch All
Processor
07h
Digital
Discrete
03h
01 – State Asserted Fatal
As
and
De
– Trig Offset A –
Catastrophic Error
(CATERR)
80h All
Processor
07h
Digital
Discrete
03h
01 – State Asserted Fatal
As
and
De
– Trig Offset M –
MTM Level Change
(MTM Lvl Change)
81h All
Mgmt Health
28h
Digital
Discrete
03h
01 – State Asserted -
As
and
De
– Trig Offset A -
Processor Population Fault
(CPU Missing)
82h All
Processor
07h
Digital
Discrete
03h
01 – State Asserted Fatal
As
and
De
– Trig Offset M –
Processor 1 DTS Thermal
Margin
(P1 DTS Therm Mgn)
83h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 2 DTS Thermal
Margin
(P2 DTS Therm Mgn)
84h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 3 DTS Thermal
Margin
(P3 DTS Therm Mgn)
85h
Platform
Specific
Temperature
01h
Threshold
01h
- - - Analog R, T A –
