IC-KP2-2HB17-2V1D
Appendix A
2014-02
109
Response:
Ele-
ment
Implicit
telegram
Use Type Description
1 Byte 0 Command code 40h Command SW
(single write words)
Byte 1 Number of double words/
Channel/Toggle bit
02h Element defines channel.
To gg l e b i t = 0
Byte 2 Status 00h Command executed.
Byte 3 Reply counter 04h For every ident telegram, the
value on the reply counter
increases by 1.
Byte 4 - 00h
Byte 5 - 00h
Byte 6 - 00h
Byte 7 - 00h
2 Byte 8 Command code 40h Command SW
(single write words)
Byte 9 Number of double words/
Channel/Toggle bit
04h Element defines channel.
To gg l e b i t = 0
Byte 10 Status 00h Command executed.
byte 11 Reply counter 04h For every ident telegram, the
value on the reply counter
increases by 1.
byte 12 - 00h
Byte 13 - 00h
Byte 14 - 00h
Byte 15 - 00h
3 Byte 16
...
Byte 23
00h Reserved
4 Byte 24
...
Byte 31
00h Reserved
