IC-KP2-2HB17-2V1D

Commands

2014-02

Figure 7.4 HW Konfig / Siemens Step7

Opening the topology editor:

1. Open the topology editor by right-clicking the Ethernet connection and then clicking the

"PROFINET IO Topology …" menu item.
