Enhanced buffered write configuration (EC)
Command:
Response:
The R/W head attempts to write a word in the configuration range to the address <ConfAddr>
until successful. After each write, the status is evaluated and the system waits until a new data
carrier is within the detection range. The command then starts again from the beginning. In
order to write in the configuration range, the password mode must be active.
The status '05h' (read/write command) is only output when a data carrier leaves the detection
range or is not yet within the detection range when the command is executed.
If two data carriers enter the read range one immediately after the other, the status '05h' is not
issued between the two readings.
Write read only code IPC11 and IDC-..-1K
"Read-after-write" operating mode is not used.
Byte Ty pe Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 1 0 1 0
Byte 2 Command code (66h) 0 1 1 0 0 1 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Reserved 0 0 0 0 0 0 0 0
Byte 5 Address in the configuration range <ConfAddr>
Byte 6 Data 00h ... FFh <Data byte 3>
Byte 7 Data 00h ... FFh <Data byte 2>
Byte 8 Data 00h ... FFh <Data byte 1>
Byte 9 Data 00h ... FFh <Data byte 0>
Byte Ty pe Bit no.
7 6 5 4 3 2 1 0
Byte 0* Telegram length, high byte 0 0 0 0 0 0 0 0
Byte 1* Telegram length, low byte 0 0 0 0 0 1 1 0
Byte 2 Command code (66h) 0 1 1 0 0 1 1 0
Byte 3 Reserved/Channel/Toggle bit 0 0 0 0 <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Table 7.25 * this byte is only used with the TCP/IP and MODBUS TCP/IP protocol.
