Pepperl+Fuchs IC-KP2-2HB17-2V1D User Manual

2014-02
96
IC-KP2-2HB17-2V1D
Technical Specifications
Interface 1
Interface 2
Conformity with Standards and Directives
Ambient Conditions
Mechanical Data
Physical Ethernet
Protocol SMTP
HTTP
TCP/IP (port 10000)
MODBUS/TCP
EtherNet/IP
PROFINET IO
Transmission rate 10 Mbit/s or 100 Mbit/s
Physical Ethernet
Protocol SMTP
HTTP
TCP/IP (port 10000)
MODBUS/TCP
EtherNet/IP
PROFINET IO
Transmission rate 10 Mbit/s or 100 Mbit/s
Directive conformity
EMC Directive
2004/108/EC
EN 61000-6-2:2006, EN 61000-6-4:2007
Standa rd conformity
Degree of protection IEC 60529:2001
Ambient temperature -25–70 °C (-13–158 °F)
Storage temperature -40–85 °C (-40–185 °F)
Climatic conditions Max. humidity 96%
Salt spray resistant in accordance with EN 60068-2-52
Shock and impact
resistance
Oscillation (sine): 5 g, 10–1000 Hz in accordance with EN 60068-
2-6
Shock (half-sine): 30 g, 11 ms in accordance with EN 60068-2-27
Degree of protection IP67
Connection Read/write heads: Shielded, 4-pin, M12 connector
Power supply: M12 connector
Protective ground: M4 grounding screw
Ethernet: M12 connector
Enclosure material Zinc, powder-coated
Mounting Screw mounting
Weight Approx. 500 g
