AS-Interface
PROFIBUS DP
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 21.12.2005
22
The detailed possibilities:
Length Description
4 bytes digital input (slaves 0 - 7)
8 bytes digital input (slaves 0 - 15)
12 bytes digital input (slaves 0 - 23)
16 bytes digital input (slaves 0 - 31)
20 bytes digital input (slaves 0 - 7B)
24 bytes digital input (slaves 0 - 15B)
28 bytes digital input (slaves 0 - 23B)
32 bytes digital input (slaves 0 - 31B)
Length Description
4 bytes digital output (slaves 0 - 7)
8 bytes digital output (slaves 0 - 15)
12 bytes digital output (slaves 0 - 23)
16 bytes digital output (slaves 0 - 31)
20 bytes digital output (slaves 0 - 7B)
24 bytes digital output (slaves 0 - 15B)
28 bytes digital output (slaves 0 - 23B)
32 bytes digital output (slaves 0 - 31B)
Length Description
16 bytes digital in/out (slaves 0 - 31)
16 Bytes digital in/out (slaves 0B - 31B)
32 bytes digital in/out (slaves 0 - 31B)
2 command interfaces can be intergrated.
Length Description
2 bytes management (command interface)
4 bytes management (command interface)
8 bytes management (command interface)
11 bytes management (command interface)
12 bytes management (command interface)
34 bytes management (command interface)
36 bytes management (command interface)
