AS-i/PROFIBUS Gateway
PROFIBUS DP
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 21.12.2005
23
Length Description
24 bytes analog input (slaves 29 - 31)
56 bytes analog input (slaves 25 - 31)
88 bytes analog input (slaves 21 - 31)
120 bytes analog input (slaves 17 - 31)
128 bytes analog input (slaves 16 - 31)
16 bytes analog input (slaves 14 - 15)
Length Description
24 bytes analog output (slaves 29 - 31)
56 bytes analog output (slaves 25 - 31)
88 bytes analog output (slaves 21 - 31)
120 bytes analog output (slaves 17 - 31)
128 bytes analog output (slaves 16 - 31)
16 bytes analog output (slaves 14 - 15)
Length Description
2 bytes … 128 bytes analog input data circuit 1, dynamic
1
2 bytes … 128 bytes analog output data circuit 1, dynamich
1
2 bytes … 128 bytes analog input data circuit 2, dynamic
1
2 bytes … 128 bytes analog output data circuit 2, dynamic
1
1. Module parameters necessarily
Length Description
2 bytes flags and AS-i detector circuit 1
2 bytes flags and AS-i detector circuit 2
