AS-Interface
Command Interface
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 21.12.2005
52
The diagnosis array is set up as follows:
Safety Monitor Diagnosis Array
"basic function range" and "sorted by OSSD"
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 00
16
1 state of monitor
2 state of OSSD1
3 state of OSSD2
4 number of devices not green, OSSD1
5 number of devices not green, OSSD2
6 device index 32, OSSD1
7 color of device 32, OSSD1
8 device index 33, OSSD1
9 color of device 33, OSSD1
… …
68 device index 63, OSSD1
69 color of device 63, OSSD1
70 device index 32, OSSD2
71 color of device 32, OSSD2
… …
132 device index 63, OSSD2
133 color of device 63, OSSD2
Safety Monitor Diagnosis Array
"enhanced function range" and "sorted by OSSD"
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 00
16
1 state of monitor
2 state of OSSD1
3 state of OSSD2
4 number of devices not green, OSSD1
5 number of devices not green, OSSD2
6 device index 32, OSSD1
7 color of device 32, OSSD1
8 device index 33, OSSD1
… …
133 color of device 95, OSSD1
134 device index 32, OSSD2
… …
261 color of device 95, OSSD2
