Result = 0 ⇒ No error, for other result codes see chapter 8.1.2 "Values for Re-
sults".
2. Write the actual slave configuration to the master
No result because toggle bit = 0.
Set the toggle bit:
The current configuration data has been written.
Request: STORE_CDI
Byte 1 07
hex
(STORE_CDI)
Byte 2 00
hex
(T = 0, master 1, single master)
Byte 3 00
hex
… …
Byte 12 00
hex
Response
Byte 1 00
hex
(or old values)
Byte 2 00
hex
(or old values)
… …
Byte 12 00
hex
(or old values)
Request: STORE_CDI
Byte 1 07
hex
(STORE_CDI)
Byte 2 80
hex
(T = 0, master 1, single master)
Byte 3 00
hex
… …
Byte 12 00
hex
Response
Byte 1 00
hex
Byte 2 80
hex
(T = 1, result = 0)
Byte 3 00
hex
(or old values)
… …
Byte 12 00
hex
(or old values)
