Using your Instrument . 23
Using the Software
The home page contains a list of folders and functions or methods. Each item in the list is
numbered and is opened by using the associated number on the keypad. Opening a folder
takes you to another screen of further options. Opening a method takes you to a Method
Settings screen where you can set the required parameters before using the method to take
measurements.
Figure 4 Features of a typical Method Settings screen
Navigation
Move between settings using the up and down arrows.
Entering Method Settings
Enter Method Settings by using the keypad numbers.
OR
If the box contains the symbol
, either type in a value or press options , and
choose an option from the next screen.
OR
If the box contains arrow symbols, use the left
and right arrows to select the
required setting.
the selected Method
Settings and go on
to the next screen
erase selections
and return to the
previous screen
To Next Page
