Table 51
Associated Diagnostic Trouble Codes
J1939 Code PDL Code
110-0
E361 (1)
110-15
E361 (2)
110-16
E361 (3)
Table 52
Troubleshooting Test Steps
Values Results
1. Check for Associated Codes
A. Connect to the electronic service tool.
B. Determine if an associated code is present.
Associated code Result: An associated code is present.
Repair: Troubleshoot the associated code. Refer to
Troubleshooting, “Diagnostic Trouble Codes” for the cor-
rect procedure.
After the repairs have been made, proceed to Test Step
6.
Result: An associated code is not present.
Proceed to Test Step 2.
2. High Ambient Air Temperature
A. Determine if the ambient air temperature is within the design
specifications for the cooling system.
Ambient Air
temperature
Result: The ambient air temperature is not within the de-
sign specifications for the system.
Repair: Verify the fan under the DEF tank is plugged in
and working (if equipped). Contact the Dealer Solutions
Network (DSN) for advice on modifications to make the
system suitable for local conditions.
After repairs have been made, proceed to Test Step 6.
Result: The ambient air temperature is within the design
specifications.
Proceed to Test Step 3.
3. Check the Electrical Connections
A. Inspect the electrical connections to the coolant diverter valve.
Inspect all electrical connections to the Diesel Exhaust Fluid
(DEF) tank header. Refer to Troubleshooting, “Electrical Connec-
tors - Inspect” for further information.
B. Inspect for corrosion or loose wires.
Corrosion Result: The connections are free of corrosion and are
not loose.
Proceed to Test Step 4.
Result: The connections are corroded and/or are loose.
Repair: Make the necessary repairs.
Proceed to Test Step 6.
(continued)
116 UENR4469-36
Symptom Troubleshooting
