Diagnostic Trouble Codes
Diagnostic Trouble Codes in J1939
Order
Table 8 lists the diagnostic trouble codes that apply to
the engines that are covered in this manual. The
codes are listed in J1939 order. Use the electronic
service tool to determine the codes that are active or
logged. Then refer to the appropriate troubleshooting
procedure for more information.
Table 8
List of Diagnostic Trouble Codes
J1939 Code and Description PDL Code and Description Troubleshooting Procedure
27-3
EGR #1 Valve Position : Voltage
Above Normal
3407-3
EGR Valve Position Sensor : Voltage
Above Normal
Troubleshooting, “Valve Position - Test”
27-4
EGR #1 Valve Position : Voltage Be-
low Normal
3407-4
EGR Valve Position Sensor : Voltage
Below Normal
Troubleshooting, “Valve Position - Test”
29-2
Accelerator Pedal Position #2 : Er-
ratic, Intermittent, or Incorrect
774-2
Secondary Throttle Position Sensor : Er-
ratic, Intermittent, or Incorrect
Troubleshooting, “Switch Circuits - Test (Multiposition Throttle
Switch)”
29-3
Accelerator Pedal Position #2 : Volt-
age Above Normal
774-3
Secondary Throttle Position Sensor :
Voltage Above Normal
Troubleshooting, “Speed Control - Test (Analog) / Speed Con-
trol - Test (PWM)”
29-4
Accelerator Pedal Position #2 : Volt-
age Below Normal
774-4
Secondary Throttle Position Sensor :
Voltage Below Normal
Troubleshooting, “Speed Control - Test (Analog) / Speed Con-
trol - Test (PWM)”
29-8
Accelerator Pedal Position #2 : Ab-
normal Frequency, Pulse Width, or
Period
774-8
Secondary Throttle Position Sensor :
Abnormal Frequency, Pulse Width, or
Period
Troubleshooting, “Speed Control - Test (PWM)”
91-2
Accelerator Pedal Position #1 : Er-
ratic, Intermittent, or Incorrect
91-2
Throttle Position Sensor : Erratic, Inter-
mittent, or Incorrect
Troubleshooting, “Switch Circuits - Test (Multiposition Throttle
Switch)”
91-3
Accelerator Pedal Position #1 : Volt-
age Above Normal
91-3
Throttle Position Sensor : Voltage Above
Normal
Troubleshooting, “Speed Control - Test (Analog) / Speed Con-
trol - Test (PWM)”
91-4
Accelerator Pedal Position #1 : Volt-
age Below Normal
91-4
Throttle Position Sensor : Voltage Below
Normal
Troubleshooting, “Speed Control - Test (Analog) / Speed Con-
trol - Test (PWM)”
(continued)
