Illustration 82 g03703137
Components of the NRS cooler
(1) NRS Exhaust outlet pipe
(2) Coolant inlet pipe
(3) NRS cooler
(4) Coolant outlet pipe
(5) NRS Exhaust inlet pipe
Table 121
Associated Codes
J1939 Code PDL Code Description
(code descriptions may vary)
110-15 E361 (1) Engine Coolant Temperature : High -
least severe
110-16 E361 (2) Engine Coolant Temperature : High -
moderate severity
110-0 E361 (3) Engine Coolant Temperature : High -
most severe
Probable Causes
• Diagnostic codes
• Coolant leak or low coolant level
• NRS cooler
Recommended Actions
NOTICE
Do not crank the engine continuously for more than
30 seconds. Allow the starting motor to cool for two
minutes before cranking the engine again.
Note: The procedures have been listed in order of
probability. Complete the procedures in order.
UENR4469-36 227
Symptom Troubleshooting
