2. Check for a Failed Sensor
A. Connect to the electronic service tool.
B. Turn the keyswitch to the ON position.
C. Disconnect a sensor on the suspect sensor supply circuit.
D. Monitor the electronic service tool when the sensor is discon-
nected to see if the active code changes to logged.
E. Connect the suspect sensor to the wiring harness
F. Repeat steps C through E for each sensor on the suspect sensor
supply.
Failed
Sensor
Result: The suspect sensor supply active code changes to
logged when a sensor is unplugged.
Repair: Replace the failed sensor.
Verify that the repair resolved the problem.
Result: The suspect sensor supply active code remains ac-
tive after all sensors on the sensor supply circuit have been
checked.
Repair: A failed wiring harness has been detected. Repair
or replace the wiring harness.
Verify that the repair resolved the problem.
If the procedure did not correct the fault, contact the Dealer Solutions Network (DSN).
i07287344
Solenoid Valve - Test
(Solenoid Valves that Connect to
the Dosing Control Unit (DCU))
This procedure covers the following diagnostic
codes:
Table 217
Diagnostic Codes for the Solenoid Valves
J1939 Code PDL Code
Code Description
(code descriptions may
vary)
Comments
3361-5 3821-5
Aftertreatment #1 DEF Dosing
Unit : Current Below Normal
The ECM detects the following conditions:
A low current condition in the output from the DCU to the solenoid in the DEF
injector
There are no active 168 diagnostic codes.
The warning lamp will come on. The diagnostic code will be logged.
3361-6 3821-6
Aftertreatment #1 DEF Dosing
Unit : Current Above Normal
The ECM detects the following conditions:
A high current condition in the output from the DCU to the solenoid in the DEF
injector.
There are no active 168 diagnostic codes.
The warning lamp will come on. The diagnostic code will be logged.
(continued)
UENR4469-36 403
Circuit Tests
