(Table 186, contd)
Troubleshooting Test Steps
Values Results
A. Refer to Test Step 9. “Check the IVS Calibration”. Record
the raw value of the throttle signal when the idle validation
switch changes from the CLOSED position to the OPEN
position.
Note: The default value for the “Idle Validation Min OFF
Threshold” is 21%. The lowest value that should be set is 5%.
The default value for the “Idle Validation Max ON Threshold” is
25%. The maximum value that is expected is 28%.
B. Set the “Idle Validation Min OFF Threshold” to 3% below the
raw value that was previously recorded.
C. Set the “Idle Validation Max ON Threshold” to 3% above the
raw value.
D. Enter the new threshold limits into the electronic service tool.
Click “Submit” on the electronic service tool screen.
E. Turn the keyswitch to the OFF position and wait at least 5
seconds. Turn the keyswitch to the ON position.
F. Repeat Test Step 9. Check that the IVS operates within the
newly set threshold limits.
Contact the Dealer Solutions Network (DSN).
i06165203
Indicator Lamp - Test
Use this procedure under the following
circumstances:
• The lamps are not receiving battery voltage.
• The lamps are not operating correctly.
The following diagnostic lamps are available:
• Wait to start lamp
• Low oil pressure lamp
• Emissions system failure lamp
• Wait to disconnect lamp
• Low DEF level lamp
• Shutdown lamp
• Warning lamp
The electronic service tool can be used as a
diagnostic aid in order to switch the individual lamps
ON and OFF.
Note: The diagnostic aid that switches the lamps is
contained in the “Override” section in the
“diagnostics” menu of the electronic service tool.
UENR4469-36 341
Circuit Tests
Copyright of Perkins Engine Company Limited. NOT FOR REPRINTING OR RESALE
