(Table 110, contd)
Troubleshooting Test Steps
Values Results
6. Ambient Temperature
A. Check for a high ambient temperature.
Note: When outside temperatures are too high, there is insuf-
ficient temperature difference between the outside air and the
intake air.
Ambient
Temperature
Result: The ambient air temperature is high.
Repair: Operate the engine at reduced speed or reduced
power.
Result: The ambient air temperature is OK.
Proceed to Test Step 7.
7. Altitude
A. Check for operation at high altitude.
Note: The cooling capacity of the ATAAC is reduced as the
engine is operated at higher altitudes.
Altitude Result: The engine is being operated at high altitude.
Repair: Operate the engine at reduced speed or reduced
power.
Result: The engine is not being operated at high altitude.
Proceed to Test Step 8.
8. Running Condition
A. Check that the engine is not operating in the lug condition.
Note: When the load that is applied to the engine is too large,
the engine will run in the lug condition. When the engine is
running in the lug condition, engine rpm does not increase
with an increase of fuel. This lower engine rpm causes a re-
duction in coolant flow through the system.
Running
condition
Result: The engine is operating in the lug condition.
Repair: Reduce the load on the engine or, if possible, in-
crease the power rating of the engine.
Result: The engine is not operating in the lug condition.
Contact the Dealer Solutions Network (DSN).
i08481019
NOx Conversion Is Low
Table 111
Diagnostic Trouble Codes for NOx Conversion Is Low
J1939
Code
PDL Code
Code Description
(code descriptions may
vary)
Comments
4364-18
E1309 (2)
Aftertreatment #1 SCR Catalyst
Conversion Efficiency : Low -
moderate severity (2)
The SCR System is not able to reduce NOx in the exhaust system.
7105-31
E1585 (2)
Aftertreatment #1 Inconsistent
Configuration Detected
Data received from the NOx sensor is not compatible with the engine software.
Follow the troubleshooting procedure to identify the root cause of the problem.
Table 112
Required Tools
Tool Part Number
Part Description Qty
(continued)
(Table 112, contd)
A T400195 Refractometer 1
B T401199 Kit - Test 1
(continued)
214 UENR4469-36
Symptom Troubleshooting
