Timeline For First Fault Occurrence
Table 144
World-Wide
DEF Quality Tampering and Dosing Interruption
-
Normal operation Level 1 Level 2 Level 3 Override
J1939 Code
-
5246-15 5246-16 5246-0
-
PDL Code
-
E1389 (1) E1389 (2) E1389 (3)
-
Inducement Time
First occurrence
None 2.5 Hours 70 minutes Shut down or idle
Until fault heals
Cycling the keyswitch
will give 20 minutes
of full power
The system must be fault free for 40 hours before the system will reset to zero. If the fault is intermittent, and returns within the 40 hours, then
the repeat inducement time will be triggered.
The override can only be used once
Repeat Inducement
time
None 5 minutes 5 minutes Shut down or idle
Until fault heals
Cycling the keyswitch
will give 20 minutes
of full power
Inducement None None None
Notification None Emission malfunction
lamp will be on solid
Emission malfunction
lamp will flash
Emission malfunction
lamp will flash
The stop lamp will be
on solid
Emission malfunction
lamp will flash
NRS Inducement
The Emissions System Malfunction lamp will
illuminate for a fault resulting from an impeded NOx
Reduction System (NRS). A first occurrence will
result in a level 1 inducement for a duration of 35
hours. Repeat occurrences will result in a level 1
inducement duration of 48 minutes.
If a fault condition exists for the entire duration of
inducement level 1, the strategy advances to
inducement level 2. The Emissions System
Malfunction lamp will flash for a fault resulting from
an impeded NRS. The duration for a level 2
inducement is always 60 minutes for the first
occurrence. Repeat occurrences will result in a level
2 inducement duration of 60 minutes.
If a fault condition exists for the entire duration of
inducement level 2, the strategy advances to
inducement level 3. The Emissions System
Malfunction lamp will flash and the Shutdown lamp
will be on. The engine will be restricted to low idle or
will stop. After the final inducement, the keyswitch
can be cycled once which will allow 20 minutes of
engine run time with full torque. After 20 minutes, the
engine will allow idle only or will stop until the fault
has been resolved. The override can only be used
once.
The system must be fault-free for 40 hours before the
system resets to zero. If the fault is intermittent and
returns within 40 hours, the repeat inducement
timings will be triggered.
UENR4469-36 265
