Injector Connectors
Connectors at the valve cover
Illustration 16 g03789439
Sensor Connectors
Analog Sensor Connector (active)
Illustration 17 g01240891
Analog Sensor Connector (passive)
Illustration 18 g01241538
Connectors for the Termination Resistor
Illustration 19 g01355248
Engine Speed/Timing Connector
Illustration 20 g01155187
UENR4469-36 27
Electronic System Overview
