(Table 8, contd)
4765-4
Aftertreatment #1 Diesel Oxidation
Catalyst Intake Gas Temperature :
Voltage Below Normal
3956-4
Aftertreatment #1 Diesel Oxidation Cata-
lyst Intake Gas Temperature Sensor :
Voltage Below Normal
Troubleshooting, “Sensor Signal (Analog, Passive) - Test”
4783-3
DPF #1 Mean Soot Signal : Voltage
Above Normal
3397-3
DPF #1 Soot Loading Sensor : Voltage
Above Normal
Troubleshooting, “Soot Sensor - Test”
4783-4
DPF #1 Mean Soot Signal : Voltage
Below Normal
3397-4
DPF #1 Soot Loading Sensor : Voltage
Below Normal
Troubleshooting, “Soot Sensor - Test”
4783-12
DPF #1 Mean Soot Signal : Failure
3397-12
DPF #1 Soot Loading Sensor : Failure
Troubleshooting, “Soot Sensor - Test”
4783-21
DPF #1 Mean Soot Signal : Data
Drifted Low
3397-21
DPF #1 Soot Loading Sensor : Data
Drifted Low
Troubleshooting, “Soot Sensor - Test”
5298-17
Aftertreatment 1 Diesel Oxidation
Catalyst Conversion Efficiency : Low
- least severe (1)
2180-1
Low Aftertreatment #1 Diesel Oxidation
Catalyst #1 Conversion Efficiency
Troubleshooting, “Diesel Oxidation Catalyst Has Low Conver-
sion Efficiency”
5576-2
Aftertreatment #1 Identification : Er-
ratic, Intermittent, or Incorrect
3468-2
Aftertreatment #1 Identification Number
Module : Erratic, Intermittent, or
Incorrect
Troubleshooting, “Aftertreatment Identification Module - Test”
5576-8
Aftertreatment #1 Identification : Ab-
normal Frequency, Pulse Width, or
Period
3468-8
Aftertreatment #1 Identification Number
Module : Abnormal Frequency, Pulse
Width, or Period
Troubleshooting, “Aftertreatment Identification Module - Test”
5576-14
Aftertreatment #1 Identification :
Special Instruction
3468-14
Aftertreatment #1 Identification Number
Module : Special Instruction
Troubleshooting, “Data Link Configuration Status - Test”
5625-3
Engine Exhaust Back Pressure Reg-
ulator Position : Voltage Above
Normal
3513-3
Engine Exhaust Back Pressure Regula-
tor Valve Position Sensor : Voltage
Above Normal
Troubleshooting, “Valve Position - Test”
5625-4
Engine Exhaust Back Pressure Reg-
ulator Position : Voltage Below
Normal
3513-4
Engine Exhaust Back Pressure Regula-
tor Valve Position Sensor : Voltage Be-
low Normal
Troubleshooting, “Valve Position - Test”
5706-5
Aftertreatment #1 Diesel Exhaust
Fluid Pump Heater : Current Below
Normal
3607-5
Aftertreatment #1 DEF Pump Heater
Relay : Current Below Normal
Troubleshooting, “DEF Pump - Test”
5706-6
Aftertreatment #1 Diesel Exhaust
Fluid Pump Heater : Current Above
Normal
3607-6
-Aftertreatment #1 DEF Pump Heater
Relay : Current Above Normal
Troubleshooting, “DEF Pump - Test”
5758-11
Aftertreatment #1 Intake Gas Sensor
Power Supply : Other Failure Mode
3621-11
Engine Exhaust NOx Level Sensor
Power Supply : Other Failure Mode
Troubleshooting, “Electrical Power Supply - Test”
5759-11
Aftertreatment #1 Outlet Gas Sensor
Power Supply : Other Failure Mode
3619-11
Aftertreatment #1 Outlet #1 NOx Level
Sensor Power Supply : Other Failure
Mode
Troubleshooting, “Electrical Power Supply - Test”
(continued)
UENR4469-36 41
Diagnostic Trouble Codes
