(Table 9, contd)
1785-13
Intake Manifold Pressure Sensor :
Out of Calibration
3563-13
Engine Intake Manifold #1 Absolute
Pressure : Out of Calibration
Troubleshooting, “Sensor Calibration Required - Test”
1797-3
Fuel Rail Pressure Sensor : Voltage
Above Normal
157-3
Engine Injector Metering Rail #1 Pres-
sure : Voltage Above Normal
Troubleshooting, “Sensor Signal (Analog, Active) - Test”
1797-4
Fuel Rail Pressure Sensor : Voltage
Below Normal
157-4
Engine Injector Metering Rail #1 Pres-
sure : Voltage Below Normal
Troubleshooting, “Sensor Signal (Analog, Active) - Test”
1797-12
Fuel Rail Pressure Sensor : Failure
157-12
Engine Injector Metering Rail #1 Pres-
sure : Failure
Troubleshooting, “Sensor Signal (Analog, Active) - Test”
2131-3
5 Volt Sensor DC Power Supply #2 :
Voltage Above Normal
3510-3
Sensor Supply Voltage 2 : Voltage
Above Normal
Troubleshooting, “Sensor Supply - Test”
2131-4
5 Volt Sensor DC Power Supply #2 :
Voltage Below Normal
3510-4
Sensor Supply Voltage 2 : Voltage Be-
low Normal
Troubleshooting, “Sensor Supply - Test”
2246-5
Glow Plug Start Aid Relay : Current
Below Normal
676-5
Engine Glow Plug Relay : Current Be-
low Normal
Troubleshooting, “Glow Plug Starting Aid - Test”
2246-6
Glow Plug Start Aid Relay : Current
Above Normal
676-6
Engine Glow Plug Relay : Current
Above Normal
Troubleshooting, “Glow Plug Starting Aid - Test”
2417-5
Ether Injection Control Solenoid : Cur-
rent Below Normal
626-5
Engine Start Enable Device 1 : Cur-
rent Below Normal
Troubleshooting, “Ether Starting Aid - Test”
2417-6
Ether Injection Control Solenoid : Cur-
rent Above Normal
626-6
Engine Start Enable Device 1 : Cur-
rent Above Normal
Troubleshooting, “Ether Starting Aid - Test”
2452-3
DPF #1 Intake Temperature Sensor :
Voltage Above Normal
3242-3
Aftertreatment #1 DPF Intake Gas
Temperature : Voltage Above Normal
Troubleshooting, “Sensor Signal (Analog, Passive) - Test”
2452-4
DPF #1 Intake Temperature Sensor :
Voltage Below Normal
3242-4
Aftertreatment #1 DPF Intake Gas
Temperature : Voltage Below Normal
Troubleshooting, “Sensor Signal (Analog, Passive) - Test”
2526-3
Air Inlet Temperature Sensor : Voltage
Above Normal
172-3
Engine Air Inlet Temperature : Voltage
Above Normal
Troubleshooting, “Sensor Signal (Analog, Passive) - Test”
2526-4
Air Inlet Temperature Sensor : Voltage
Below Normal
172-4
Engine Air Inlet Temperature : Voltage
Below Normal
Troubleshooting, “Sensor Signal (Analog, Passive) - Test”
2738-3
Turbocharger #1 Compressor Inlet
Pressure Sensor : Voltage Above
Normal
1176-3
Engine Turbocharger #1 Compressor
Inlet Pressure : Voltage Above
Normal
Troubleshooting, “Sensor Signal (Analaog, Active) - Test”
2738-4
Turbocharger #1 Compressor Inlet
Pressure Sensor : Voltage Below
Normal
1176-4
Engine Turbocharger #1 Compressor
Inlet Pressure : Voltage Below Normal
Troubleshooting, “Sensor Signal (Analaog, Active) - Test”
(continued)
46 UENR4469-36
Diagnostic Trouble Codes
