Illustration 176 g03826889
Throttle Mode Configuration
The throttle configuration screen allows the ECM to
be configured with up to two channel inputs. The
inputs can be a combination of three types of speed
control input. The three types of speed control input
are:
• PWM throttle input providing a variable duty cycle
input to control engine speed
• Analog throttle input providing a variable voltage
signal to control engine speed
• Multi-Position Throttle Switch (MPTS) which uses
up to four switch inputs giving a total of 16
combinations. Each switch combination can then
be programmed with a desired engine speed,
which can be selected by the operator.
The permitted throttle combinations are shown in the
following table:
Table 239
Channel 1 Channel 2
None None
PWM None
None PWM
(continued)
UENR4469-36 477
