(Table 9, contd)
3386-4
EGR Temperature Sensor : Voltage
Below Normal
412-4
Engine Exhaust Gas Recirculation
Temperature : Voltage Below Normal
Troubleshooting, “Sensor Signal (Analog, Passive) - Test”
3387-2
EGR Differential Pressure Sensor :
Erratic, Intermittent, or Incorrect
411-2
Engine Exhaust Gas Recirculation
Differential Pressure : Erratic, Inter-
mittent, or Incorrect
Troubleshooting, “Sensor Signal (Analog, Active) - Test”
3387-3
EGR Differential Pressure Sensor :
Voltage Above Normal
411-3
Engine Exhaust Gas Recirculation
Differential Pressure : Voltage Above
Normal
Troubleshooting, “Sensor Signal (Analog, Active) - Test”
3387-4
EGR Differential Pressure Sensor :
Voltage Below Normal
411-4
Engine Exhaust Gas Recirculation
Differential Pressure : Voltage Below
Normal
Troubleshooting, “Sensor Signal (Analog, Active) - Test”
3387-13
EGR Differential Pressure Sensor :
Out of Calibration
411-13
Engine Exhaust Gas Recirculation
Differential Pressure : Out of
Calibration
Troubleshooting, “Sensor Calibration Required - Test”
3397-3
DPF #1 Soot Loading Sensor : Volt-
age Above Normal
4783-3
DPF #1 Mean Soot Signal : Voltage
Above Normal
Troubleshooting, “Soot Sensor - Test”
3397-4
DPF #1 Soot Loading Sensor : Volt-
age Below Normal
4783-3
DPF #1 Mean Soot Signal : Voltage
Above Normal
Troubleshooting, “Soot Sensor - Test”
3397-12
DPF #1 Soot Loading Sensor : Failure
4783-12
DPF #1 Mean Soot Signal : Failure
Troubleshooting, “Soot Sensor - Test”
3397-21
DPF #1 Soot Loading Sensor : Data
Drifted Low
4783-21
DPF #1 Mean Soot Signal : Data
Drifted Low
Troubleshooting, “Soot Sensor - Test”
3405-5
EGR Valve Control : Current Below
Normal
2791-5
Engine Exhaust Gas Recirculation
(EGR) Valve Control : Current Below
Normal
Troubleshooting, “Motorized Valve - Test”
3405-6
EGR Valve Control : Current Above
Normal
2791-6
Engine Exhaust Gas Recirculation
(EGR) Valve Control : Current Above
Normal
Troubleshooting, “Motorized Valve - Test”
3407-3
EGR Valve Position Sensor : Voltage
Above Normal
27-3
EGR #1 Valve Position : Voltage
Above Normal
Troubleshooting, “Valve Position - Test”
3407-4
EGR Valve Position Sensor : Voltage
Below Normal
27-4
EGR #1 Valve Position : Voltage Be-
low Normal
Troubleshooting, “Valve Position - Test”
3468-2
Aftertreatment #1 Identification Num-
ber Module : Erratic, Intermittent, or
Incorrect
5576-2
Aftertreatment #1 Identification : Er-
ratic, Intermittent, or Incorrect
Troubleshooting, “Aftertreatment Identification Module - Test”
3468-8
Aftertreatment #1 Identification Num-
ber Module : Abnormal Frequency,
Pulse Width, or Period
5576-8
Aftertreatment #1 Identification : Ab-
normal Frequency, Pulse Width, or
Period
Troubleshooting, “Aftertreatment Identification Module - Test”
(continued)
UENR4469-36 49
Diagnostic Trouble Codes
