RECHECKING CABLE “A”, USING MAP “B”
* TO RETURN TO MENU “TIME” “DATE”
FAULT IN FIRST 50 FEET OF CABLE ?
# TO SILENCE ALARM “TIME” “DATE”
LEAK DETECTED IN CABLE ? AT ???? FEET
# TO SILENCE ALARM “TIME” “DATE”
CABLE ? DRYING AT ???? FEET
# TO SILENCE ALARM “TIME” “DATE”
BREAK DETECTED IN CABLE ? AT ???? FEET
# TO SILENCE ALARM “TIME” “DATE”
SHORT DETECTED IN
CABLE ? AT ???? FEET
# TO SILENCE ALARM “TIME” “DATE”
PROBE # ?? ACTIVATED IN CABLE ?
# TO SILENCE ALARM “TIME” “DATE”
PROBE # ?? RESET IN CABLE ?
# TO SILENCE ALARM “TIME” “DATE”
NO
END FOUND IN CABLE ? IN ???? FEET
# TO SILENCE ALARM “TIME” “DATE”
LCD2.4-04:
PAL-AT displays this message when it first recognizes a fault condition. PAL-AT rechecks the cable three
(3) times during the next few seconds before displaying an actual alarm condition and activating the alarm
relays.
2.4.2 Fault Messages Displayed
One of the following messages is displayed when a fault is detected:
LCD2.4-05:
OR
LCD2.4-06:
OR
LCD2.4-07:
OR
LCD2.4-08:
OR
LCD2.4-09:
OR
LCD2.4-10:
OR
LCD2.4-11:
OR
LCD2.4-12:
A display above is on for 5 seconds and then alternates with display LCD2.4-04.
