Controls
7 - 5
7.09 Feed regulator (on machines with automatic backtacking mechanism
and presser foot lift -911/97)
● The forward stitch length is set by turning
the knurled screw 1.
● The reverse stitch length is set by turning
the knurled screw 2.
You can set the length of the
reverse stitch as long as
required, independent of the
foward stitch.
The options for setting the
automatic start and finish
backtacks are to be found in the
instruction manual of the motor.
Fig. 7 - 09
2
1
