8 - 1
Installation and commissioning
8 Installation and commissioning
The machine must only be installed and commissioned by qualified personnel!
All relevant safety regulations are to be observed!
If the machine is delivered without a table, it must be ensured that the stand and
the table top which you intend to use can hold the weight of the machine.
Adequate stability of the base must be guaranteed - during sewing too.
8.01 Installation
The necessary connections for electricity and compressed air, a level and stable surface and
sufficient lighting must be available at the machine’s location.
Due to reasons of packaging, the table top is lowered during transport. The
following is a description of how to adjust the height of the table top.
8.01.01 Adjusting the table-top height
● Loosen screws 1 and 2 and adjust the table top to the required height.
● Tighten screws 1.
● Adjust the pedals to the required setting and tighten screw 2.
Fig. 8 - 01
1
1
2
