Adjustment
11 - 1
11 Justierung
The illustrations in this section show the two-needle machines.
For the PFAFF 1293 single-needle machine, various adjustments only have to be
made on one side, i.e. in the right hook compartment.
11.01 Notes on adjusting
All adjustments in these adjustment instructions are based on a completely installed machine
and must only be carried out by appropriately
trained mechanics. Covers on the machine,
which have to be removed and replaced for checks and adjustment work, are not mentioned
here.
The screws and nuts in brackets ( ) are for securing machine parts which are to be loosened
before making the adjustment and tightened again after the adjustment has been carried out.
11.02 Tools, gauges and other accessories
●Screwdrivers with blade widths from 2 to 10 mm
●Screwdrivers with blade widths from 7 to 14 mm
●Allen keys from 2 to 6 mm
●Metal rule (part No. 08-880 218-00)
●Needle rise gauge (part No. 61-111 600-02)
●Adjustable clamp (part No. 61-111 600-35/001)
●Needles, system 134
●Sewing thread and test material
11.03 Abbreviations
TDC = top dead center
BDC = bottom dead center
