Adjustment
11 - 30
●
Turn shaft
2
according to
Requirement.
●
Tighten screws
1
.
When tightening screws
1
make sure that all transmission parts of the thread
catcher drive can move freely.
1
2
4
3
Fig. 11 - 28
4 mm
3
11
.05.08
Thread catcher resting position
Requirement
When the thread trimmer is in its resting poistion there must be a clearance of about
4 mm
between the point of catcher
3
and the cutting edge of knife
4
.
64
