Adjustment
11 - 5
11.04.04 Centering the needle in the needle hole
Requirement
With the stitch length set at „0“, the needle must enter the needle hole exactly in the
middle.
Fig. 11 - 04
Loosen screws 1, 2 and 3.
Position the needle directly above the feed dog by turning the balance wheel.
Position needle bar frame 4 in accordance with the requirement.
Tighten screws 1, 2 and 3.
2
4
1
3
