Care and maintenance
10 - 2
Switch off the machine!
Danger of injury due to unintentional starting of the machine!
● Oil all bearing parts above the table top twice a week
● Remove screw 1 and tilt machine
backwards.
● Apply oil at all bearing points beneath the
table (see arrows) twice a week.
Set the machine upright with
both hands! Danger of crushing
between sewing head and
table!
● Tighten screw 1 again.
Only use oil with a viscosity of
22.0 mm
2
/s at 40° C and a
density of 0.865 g/cm
3
at 15°C!
We recommend PFAFF sewing-
machine oil, part
No. 280-1-120144.
10.03 General oiling
Fig. 10 - 02
Fig. 10 - 03
1
