11 - 2
Adjustment
11.
04
Adjusting the basic mac
hine
11.
04.0
1
Lateral positioning of the feed dog
Requirement
T
he clearances from the lef
t and right of the bot
tom f
eed dog
1
to the needle plate cutout
must be the the same size.
ā
Mov
e the bottom f
eed dog
1
(screws
2
) in accordance with the
requirement.
2
1
X
=
X
Fig. 11 - 01
32
34
