Operating Controls
16
7.03 Pedal
O With the main switch turned on.
The functions of the pedal depend
on the selected operating mode, see
chapter 10 Sewing.
O In manual sewing:
0 = Neutral position
+1 = Sewing
- 1 = Raise sewing foot
- 2 = Trim thread
O In programmed sewing:
0 = Neutral position
+1 = Start sewing cycle
- 1 = No function
- 2 = Seam stop
0
-2
-1
Fig. 7 - 03
+1
Fig. 7 - 04
7.04 Hand lever to raise the sewing foot
O Turning the hand lever 1 raises the
sewing foot.
1
