Maintenance and Care
67
12.06 Cleaning the blower air filter
O Remove the cover 1.
O Remove the filter element and
blow it out with compressed air.
O Insert the cleaned filter element
and replace the cover 1.
Fig. 12 - 05
1
Fig. 12 - 04
2
1
12.05 Cleaning the maintenance unit air filter
Switch off the machine!
Detach the compressed air
tube on the maintenance unit
Emptying the water tank:
O The water tank 1 empties itself automat-
ically after the compressed air tube for
the maintenance unit has been removed.
Cleaning the filter:
O Unscrew the water tank 1 and take out
the filter 2.
O Clean the filter 2 with compressed air or
isopropyl alcohol (order no. 95-665 735-
91).
O Screw in the filter 2 and screw on the
water tank 1.
10
12
0
6
4
2
8
16
14
100
50
150
0
200
230
