Input
59
11.02.03 List of parameters
Group
Parameter
Description
User level
Setting range
Set value
1
105 Speed for seam start B,C 300 - 1500 1000
110 Speed for seam end B,C 300 - 1500 1000
116 Soft starting stitches B,C 0 - 30 0
117 Speed for soft starting stitches B,C 30 - 1000 400
3
382 Analogue input switching threshold for the
thread monitor
B,C 0 - 100 15
387 Output Ax (motor operation) is active
ON = with the pedal 1D (motor running);
OFF = with the pedal 1 (lower presser foot)
B,C ON - OFF ON
4
452 "Lock-out" input
ON = yes
OFF = no (no function)
B,C ON - OFF ON
5
521 Needle position at sewing stop before seam
end
ON = needle position "2" (top)
OFF = needle position "1" (bottom)
B,C ON - OFF ON
538 Output timing Ax (thread tension release) B,C 10 - 50 30
6
605 Actual speed on the display
ON = yes
OFF = no
B,C ON - OFF OFF
606 Speed stage 1 (min.) B,C 30 - 300 180
607 Speed stage 12 (max.) B,C 300 - 3500 2500
609 Trimming speed 1 B,C 60 - 300 180
615 End detection by light barrier
ON = from light to dark;
OFF = from dark to light
B,C ON - OFF ON
618 Reverse rotation after seam end
ON = yes
OFF = no
B,C ON -OFF ON
623 Switch-on delay for reverse rotation [ms] B,C 0 - 2000 30
