Sewing
42
O Call up "teach-in mode". (The LED in the key flashes.)
O Insert the workpiece, see chapter 9.09 Inserting the workpiece.
O Stitch the first seam zone to the first corner using the pedal function (e.g. 32 stitches).
O Call up corner programming. (LED in the key lights up.)
1
22 2.2
3223
O Select the desired turn (e.g. 23 mm) by pressing the +/- keys (D).
O Switch on the "Turn corner" function for the seam zone. The turn is performed
(The turning range can be corrected by pressing the +/- keys (S)).
O Select the second seam zone by pressing the +/- keys (A).
2
2200 2.2 7
O Select the desired speed (e.g. 2200) by pressing the +/- key (B; C)
O Select the desired value for the stitch length (e.g. 2.2 mm) by pressing the +/- keys
(P; S).
O Stitch the second seam zone using the pedal functions (e.g. 7 stitches).
O Call up corner programming. (LED in the key lights up.)
2
22 2.2
710
