Pfaff 3827-2 - Preparation; Inserting the Needle; Winding the Bobbin Thread, Adjusting the Thread Tension

Preparation
11 - 1
11 Preparation
11.01 Inserting the needle
Turn the machine off!
● Bring the needle bar into its highest
position.
● Loosen the needle retaining screw 1.
● Insert the needle 2 as far as possible.
● The long needle-groove must be facing
left when looking in the direction of
sewing.
● Tighten the needle retaining screw 1.
Attention:Needle point and
knife blade! Danger of injury!
11.02 Winding the bobbin thread, adjusting the thread tension
● Set the bobbin winder into gear by
pressing in the bobbin winder spindle 1.
Papidly rotating bobbin!
Danger of Injury!
● Regulate the thread tension by turning
the milled screw 2.
Fig. 11 - 01
1
Fig.11 - 02
+
_
1
2
