Pfaff 3827-2 - Vibrating Presser Lifting Motion

Adjustment
14 - 18
14.16 Vibrating presser lifting motion
Requirement
With the stitch length set at 2 and the ascending feed dog at the top edge of the needle
plate, the vibrating presser must be touching the feed dog (see arrow).
● Turn eccentric pin 1 (screw 2) in accordance with the requirement.
2
1
Fig. 14 - 16
