Programming and sewing
12 Programming and sewing
With this machine the fullness is applied to the top layer of material. Therefore,
take care to ensure that the workpiece is appropriately inserted.
12.01 Semi-automatic operation
Programming and sewing
To select semi-automatic sewing, switch 6 must be down. During semi-automatic operation
switches 4, 5, 7 and 8 should be up (see Fig. 8 - 05). The positions of switches 1, 2, 3 and 9
can be chosen at your discretion.
Change to programming mode with button G and move to the position of the stitch counter
which have to be altered with button F.
The current position blinks.
Alter the current position with buttons + and -.
Exit from programming mode by pressing button G again.
12 - 1
Fig. 8 - 05
615234
9
87
