Pfaff 3827-2 - Limiting the Stitch Length

Adjustment
14 - 32
14.30 Limiting the stitch length
● Loosen screw 1 (accessible through the assembly hole) or screw it out according to the
limit to be set.
● Set the stitch length control lever 2 at the desired maximum stitch length.
● Set the limiting angle 3 from above so that it touches the control lever 2 and secure it (in
the desired position) by tightening screw 1 in either the lower or upper hole.
3
1
2
Fig. 14 - 30
