Pfaff 3827-2 - Pressure on Vibrating Presser and Presser Foot

Adjustment
14 - 31
14.29 Pressure on vibrating presser and presser foot
Requirement
The proper feeding of the material must be ensured even at top sewing speed. There must
not be any pressure marks on the material.
● Pressure on vibrating pressure - Set regulating screw 1 flush with the top surface of the
machine housing.
● Pressure on presser foot - Turn regulating screw 2 (milled nut 3) until there is a clearance
of approx. 12 mm between the screw shoulder and the machine housing.
If necessary, the pressure on the vibrating presser and the presser foot can be
increased (+) or decreased (-).
+
+
_
1
2
3
_
12 mm
Fig. 14 - 29
