Pfaff 3827-2 - Zeroing the Top Feed Motion

Adjustment
14 - 14
14.13 Zeroing the top feed motion
Requirement
With the stitch length and the top feed set at 0 and with the alignment gauge 8 attached
there should be no movement of the feed driving lever 18 when the handwheel is turned.
7
6
5
12
14
15
17
16
8
13294
18
Fig. 14 - 12
