Adjustment
14 - 37
14.35 Synchronizer
Requirement
When stopping sewing, the machine must position itself at approx. 4 mm after the BDC of
the needle bar.
After trimming the thread the machine must position itself in the TDC of the take-up lever.
When pressing the pedal backwards the plunger of the cylinder must extend when the
needle bar is 20 - 22 mm after its BDC.
ā For the adjustment see the instruction manual of the motor manufacturer.
