Mounting and initial operation
9 Mounting and initial operation
This machine may only be mounted and put into operation by qualified
specialists! All relevant safety regulations are not to be adhered to!
9.01 Mounting
Connections for electrical and compressed air supplies must be available at the machine’s
location (see chapter 3 Specifications).
A solid, horizontal surface and adequate lighting must also be guaranteed.
9.02 Initial operation
● Check the machine for any possible damage, especially the electrical and pneumatic
leads.
● Clean the machine thoroughly and then oil it (see chapter 13 Maintenance and Care).
● Connect the machine to the power supply.
● Connect the machine to the compressed air supply. The manometer should display an
air pressure level of. 6 bar. Adjust to this value if necessary.
● Before the initial operation remove the
stopper from hole 1.
The stopper serves only to
secure the machine for
transport and must not be used
while sewing!
Abb. 9 - 01
1
9 - 1
