Adjustment
14 - 11
● Raise the presser bar 8 and place the 5 mm adjustment gauge underneath the gauge
foot.
● Loosen screw 9 and press the pin out 10.
● Loosen screw 11.
● Position the gauge foot so that its edge is parallel to the needle plate cutout.
● Lower the lifting piece 12 until it comes to rest and tighten screw 11.
Do not mount pins 5 and 10.
Leave screws 4 and 9 loosened for the following adjustment.
